Gazco Evolution Logic E Box Gas Fire
Maximum heat output (NG) 3.8Kw Efficiency rating of up to 77% (NG) Manual control with optional extra standard or thermostatic remote control available Coal or Pebble fuel effect Glass fronted inset fire Brushed Stainless steel finish Suitable for Class 1, 2, prefabricated** & precast flues* Natural or Propane gas versions available Depth of 215mm fully inset If you would like to see a Gazco Logic Ebox in live operation see the Video below under the Notes Section

Finishes

Gazco Evolution Brushed Stainless Steel Frame Gazco

Fuel Effects

Gazco Coals

Gazco Pebbles

Gas Types

Gazco Natural Gas (NG)

Gazco Propane Gas (LPG)

Controls

Gazco Rotary Manual Control	Gazco Standard Remote Control	Gazco Thermostatic Remote Control

Optional Extras

Please call 0845 301 5552 for a price

Specification

External Dimensions H See Table mm W See Table mm D See Table mm Inset Dimensions H 560mm W 410mm D 215/250mm OutPut (NG) Maximum heat output high 3.8Kw Maximum heat input high 5.0Kw (LPG) Maximum heat output high 3.7Kw Maximum heat input high 4.8Kw

Details Modern Glass Fronted Inset Gas Fire Flue Suitable for class 1 chimneys, class 2, prefabricated** & precast flues.* Ventilation An air vent is not normally required

Notes

Video Link

Arts		510	605	50
Designio		595	615	68
Dimension		540	635	68
Evolution		489	597	68
Fusion		520	1127	38
Futura		520	1127	38
Holyrood		490	600	50
Infiniti		620	710	75
Progress		520	598	60
Spanish		490	600	50
Richmond		540	635	50
Stockton Inset		529	601	128
Winchester		508	619	55
Decorative		505	610	50
Profil		490	600	50

NOTE: Please ensure to have a survey carried out by a Corgi registered gas installer to check and certify the compatibility of your chimney or flue with this fire before making any purchase to avoid disappointment. *If you intend to install this fire into a precast flue an optional extra spacer kit (price on application) and or a 3" 75mm deep rebated fire surround will be required. **Also due to the sheer number of varying flue boxes it is not possible to know which fires are suitable until such time as the exsisting fire has been removed. Also be aware that due to the fire producing heat the interior of the fire may become marked over time through general wear and tear which is quite normal and to be expected. Gazco standard remote control option allows the flame height to vary between high and low from your armchair once the pilot has been ignited manually. Whereas the thermostatic remote offers all the same benefits as the standard remote control, you also have the added benefit of being able to programme the fire to switch itself on and off twice a day and to heat the room to the temperature you select.

For more detailed information about this product including down loadable technical user & installation instructions or to request a brochure visit www.gazco.com info@gazco.co.uk
